Cushman Shuttle 4 Gas
Effortlessly work around your facility with the reliable Shuttle 2, equipped with a 20.9-square-foot cargo deck that has the space and capacity to fit all your hospitality needs. Now offered with maintenance-free ELiTE lithium powered by Samsung SDI Technology or a fuel-efficient 13.5 hp electronic fuel injection gas engine, the Shuttle 2 offers the efficiency and durability to get the job done.
- 9-SQ-FT Cargo Deck
- Standard Brush Guard and Headlights
| Frame | Welded Steel w/ DuraShield™ Powder Coat |
|---|---|
| Body & Finish | Injection Molded TPO (Front) Steel Base Coat/Clear Coat (Rear) |
| Standard Color | Patriot Blue |
| Overall Length | 135.0 in (343 cm) |
| Overall Width | 48.5 in (123 cm) |
| Overall Height | 48.6 in (123 cm) (w/o Roof) 72.0 in (183 cm) (w/ Struts & Roof) |
| Wheel Base | 93.5 in (237 cm) |
| Wheel Track | 34.2 in (87 cm) Front 38.0 in (97 cm) Rear |
| Ground Clearance | 4.3 in (11 cm) |
| Cargo Deck Capacity | 9-cu-ft (0.25 m3) |
| Power Source | 4-Cycle, 24.5 ci (401cc) |
| Valve Train | Single Cylinder OHV |
| Horsepower (KW) | 13.5 hp (10.1 kW) |
| Electrical System | Starter/Generator. Solid State Regulator |
| Battery (Qty/Type) | One, 12V Maintenance Free |
| Key or Pedal Start | Pedal |
| Air Cleaner | Replaceable Dry Cartridge |
| Lubrication | Pressurized Oil System |
| Oil Filter | Spin-On |
| Fuel Capacity | 6 Gallon (22.7 L) Tank |
| Drive Train | Continuously Variable Transmission (CVT) |
| Transaxle | Differential w/ Helical Gears |
| Gear Selection | Forward – Reverse |
| Rear Axle Ratio | 11.47:1 (Forward) 14.35:1 (Reverse) |
| Seating Capacity | 4-Person |
| Curb Weight | 936 lb (425 kg) |
| Vehicle Load Capacity | 1200 lb (544 kg) |
| Bed Load Capacity | 400 lb (181 kg) |
| Speed | 14 mph ± 0.5 mph (22.5 kph ± 0.8 kph) |
| Steering | Self-Compensating Rack & Pinion |
| Suspension | Leaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear) |
| Service Brake | Rear Wheel Mechanical, Self-Adjusting Drum |
| Parking Brake | Self-Compensating, Single-Point Engagement |
| Tires | 18 x 8.5 – 8 (4 Ply Rated) |
| Cooling System | Air Cooled |
